MAIN FEATURES

  • Important design.
  • Structure and arms in AISI 304 steel (optional AISI 316 or painted)
  • Status and passage indicators.
  • Operating mode configurable via Dip-Switch, PC or dedicated App.
  • Compatibility with any third-party access control via input/output with dry contacts.
  • Emergency mode with horizontal drop arm.
  • Optional modules for connection via RS232, RS485, TCP/IP.
  • Integrated Wi-Fi module.
Intended use Indoors, outdoors
Intensity of use 100%, 7/24 use
Power supply (V - 50/60 Hz) 110/220 AC
Weight (Kg) 48
Operating temperature (°C) -20 to +68 (with heater -50)
Manual range (pass/min) 30
Max. manual range (cycles/min) 82
Motor.driven range (pass/min) 25
Max. motor-driven range (cycles/min) 75
Material 304 AISI stainless steel
Finish Orbital brushed matt
