Cutting-edge 24V brushless underground motor for gates up to 4 meters and 400 kg. Designed for rapid movements, allowing a 90° opening in just 10 seconds. It features a brand-new control board with CXN BUS, a graphic display for quick installation, and includes 4 configurable safety inputs for direct management of resistive safety edges. FROG-X is fully compatible as a replacement of previous FROG installations. A new high-performance accessory is available for 180° openings.
Leaves up to 4 m
| MODELS | 801MI-0030 |
|---|---|
| Protection rating (IP) | 67 |
| Power supply (V - 50/60 Hz) | 24 DC |
| Power supply to motor (V) | 24 DC |
| Absorption (A) | 15 |
| Power (W) | 200 |
| Maneuvering time at 90° (s) | 10-18 |
| Cycles/Hour | CONTINUOUS DUTY |
| Torque (Nm) | 300 |
| Operating temperature (°C) | -20 ÷ +55 |
FRG40DGX -Irreversible 24 V brushless underground operator with native encoder, Adaptive Speed & Torque Technology, motion management, obstacle detection and adjustable closing leaf stop for swing gates with leaves up to 4 m and 400 kg weight. FROG-X is driven by the dedicated control panel 801QA-0170.
