RBE Plus

The RBE Plus series controller is a robust modular board capable of managing up to 5,000 users, making it ideal for large-scale automation systems. It supports all CAME codes, including TOP, TAM, TWIN, and ROLLING CODE, using AF43S or AF868 boards. The RBE Plus can also manage up to 8 CXN BUS selectors and 4 CAME automation systems via CRP, with 4 inputs and outputs for enhanced control. It is available in 12-24 V AC/DC or 120-230 V AC versions, and can be easily connected to CAME CONNECT via a gateway for remote management and monitoring.

RBE is the control panel for access control, specific for use with CAME CXN BUS transmitters and accessories.
They manage up to 5000 users and are available in 12 - 24 V AC/DC or 120 - 230 V AC versions.
It is possible to connect up to 8 CXN BUS devices thanks to the 806XG-0110 accessory.

MAIN FEATURES

Simultaneous management of transmitters, keyboards and transponders
Management of up to 5,000 users
Connection of up to 8 CXN BUS accessories
4 relay outputs
4 digital inputs
Direct management of up to 4 CAME automations via CRP

Integrated clock for managing time slots
Advanced Quick & Easy with Code Function implemented directly on the keyboards
Event log for access control
CAME Key slot
Easy installation on DIN rail

Quick & Easy

Timed access solution. Ideal for holiday homes, B&B's & short term lettings

Manage temporary access to facilities such as holiday accommodation with the "Quick & Easy" tools embedded into the RBE Plus when combined with a 4G gateway.

Well suited for B&B's, small hotels, camp sites, holiday lets and short term lettings, the RBE can simplify guest access.
Generate unique access codes for visitors to enter when they arrive meaning no one needs to be on hand, especially useful for late arrivals.

The code is active from the check-in and check-out times specified and it's emailed directly to the guest.

No physical keypads installed? Use a virtual, web-based keypad on guests smartphones, in-browser, no App required.
Hosts can remotely monitor the event log to ensure guests have gained access.

FIND OUT MORE ABOUT QUICK & EASY

TECHNICAL CHARACTERISTICS

MODELS	806RV-0060	806RV-0070
Protection rating (IP)	54	54
Power supply (V)	24	120/230
Radio signal frequency (Mhz)	433,92 - 868,35	433,92 - 868,35
Power (W)	15	13.5
Operating temperature (°C)	-20° ÷ 55°C	-20° ÷ 55°C
Material	ABS	ABS

OUR RANGE

Control panels for 24 V DC geared motors tested according to EN 12453 standards

801QA-0050

Multifunction control panel, with 230 V AC power supply, for 24 V double-leaf swing gates, with programming and signaling display, self-diagnosis of safety devices, Adaptive Speed & Torque Technology, CXN BUS, 2 safety inputs and storage of up to to 250 users.

Download ZLX24 conformity declaration (CE)

801QA-0060

Multifunction control panel, with 230 V AC power supply, for 24 V double-leaf swing gates, with graphic programming and signaling display, self-diagnosis of safety devices, Adaptive Speed & Torque Technology, CXN BUS, 4 safety and storage inputs up to 1000 users.

Download ZLX24 conformity declaration (CE)
