Soluzione specifica per parcheggi e passaggi ad uso continuo
Passaggio utile fino a 3,8 m
The DC motor with brushless technology ensures reduced noise and low maintenance costs. It also allows precise control of movements and torque at different speeds.
Tested for continuous use, suitable for intensive duty contexts, it's the perfect solution for parking systems
On the crown and on the boom there is a coloured LED lighting system (red and green) with traffic light function, which can also be integrated with parking systems.
ADDITIONAL FUNCTIONS
The electronic board is placed on the upper crown to allow convenient and easy intervention.
It is equipped with a graphic display with configuration wizard, 3 safety inputs that can also be configured as resistive and a USB port for updating and saving the settings.
FIND OUT MOREThe special accessory for installations in rooms with low ceiling, where there is not enough space for the boom in a completely open position.
The connection to the CAME Cloud enables remote control of the operators and complete customer management. Thanks to CAME Connect it is possible to offer an efficient and continuous maintenance service, a remote assistance support and a rapid intervention in case of malfunction.
FIND OUT MORE ABOUT CAME CONNECT
| MODELLI | 803BB-0120 |
|---|---|
| Grado di protezione (IP) | 54 |
| Alimentazione (V - 50/60 Hz) | 100 AC ÷ 240 AC |
| Alimentazione motore (V) | 36 DC |
| Potenza (W) | 270 |
| Tempo di apertura a 90° (s) | 1 ÷ 2 |
| Intermittenza/Lavoro (%) | SERVIZIO CONTINUO |
| Temperatura d’esercizio (°C) | -20 ÷ +55 (-40 con art. 803XA-0260) |
| Colore RAL | 7043 |
GPX40MGS - Barriera automatica con motoriduttore brushless irreversibile; armadio in acciaio zincato e verniciato.
Download FASCICOLO GPX40MGS - GPX40MGP MULTI4A A4 (IT, EN, FR, RU)
Download GARD PX conformity declaration (CE)
Scheda di interfaccia per la gestione di due automazioni o per l'abilitazione del protocollo CRP.
Download FASCICOLO RSE MULTI (IT, EN, FR, DE, ES, NL)
Download RSE conformity declaration (CE)
Scheda di decodifica e gestione controllo accessi con transponder.
Scheda di decodifica e gestione controllo accessi con selettori a tastiera.
Molla di bilanciamento Ø 40 mm.
Molla di bilanciamento Ø 50 mm.
Molla di bilanciamento Ø 55 mm.
Strip LED rosso/verdi per asta fino 4 m.
Kit collegamento fra strip LED per asta con snodo HD (Heavy Duty).
