Solution for applying in private homes and apartment buildings, on large-sized gate posts
| MODELS | FE4024 | FE4024V | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| LEAF OPENING (°) | A | B | D | E | C Max. | A | B | D | E | C Max. |
| 90 | 150 | Min. 390 | - | - | 380 | - | - | - | - | - |
| 120 | 200 | Min. 390 | - | - | 0 | - | - | - | - | - |
| MODELS | FE4024 | FE4024V |
|---|---|---|
| Protection rating (IP) | 44 | 44 |
| Power supply to motor (V) | 24 DC | 24 DC |
| Absorption (A) | 7 Max. | 5 Max. |
| Power (W) | 130 | 150 |
| Maneuvering time at 90° (s) | ADJUSTABLE | ADJUSTABLE |
| Duty/cycle (%) | HEAVY-DUTY SERVICE | HEAVY-DUTY SERVICE |
| Thrust (N) | 360 | 360 |
| Operating temperature (°C) | -20 ÷ +55 | -20 ÷ +55 |
Multifunction control panel for swing gates with two leaves, graphic programming and alerts display, plus self-diagnosing safety devices and on-board radio decoding.
Multifunction control panel for swing gates with two leaves, graphic programming and alerts display, plus self-diagnosing safety devices and on-board radio decoding.
Irreversible 24 V gearmotor, with hinged transmission arm and C Max. 380 mm for swing gates with up to 4 m leaves that weighs up to 400 kg.
Irreversible 24 V gearmotor, rapid version, with hinged transmission arm and C Max. 380 mm for swing gates with up to 4 m leaves that weighs up to 400 kg.
Multifunction control panel for swing gates with two leaves, graphic programming and alerts display, plus self-diagnosing safety devices and on-board radio decoding.
Circuit board for emergency operation and battery charging.
Circuit board for emergency operation and battery charging.
Single cylinder electric lock.
Double cylinder electric lock.
Case for remote release with customized key, plus pull-cord handle and control button. Cord length L = 5 m.
