The semi-automatic version of the G6 EVO bollard can stop a 2.5T pick-up travelling at 48 km/h. It’s an ideal solution to secure schools, shopping centers, hotels or appartment buildings, where the level of security is moderate.
Removable jacket & easier maintenance
The G6 EVO bollard is equipped with an innovative interchangeable sleeve system for customizing the aesthetics of access points and refurbish any damaged bollard heads in less than 5 minutes. The bollard is composed of a raw cast iron head, which provides high impact resistance, covered with a sleeve in steel or stainless steel. The new G6 EVO concept makes on site jacket replacement easy and quick, without using any hoisting means.
G6EVO - Bornes escamotables semi-automatique
Conception: Urbaco Monobloc® certificate : 3 elements of structure : casing, cover and bollard head each molded one piece spheroidal cast iron material.
Use: Occasional openings
Material: 11mm average thick cast-iron material
Reflective band: Class II reflective band (White)
Protection of the lock: The key opening is protected by a bronze cover plate stopping the ingress of dust or gravel.
Standard imprint key: E11 (The locking key matches with the imprint of the lock rod)
Operating safety: Reinforced push-to-release bar and lock bolt
Impact resistance: Ø200 : Middle (1,2T at 50km/h), Ø250 : High (2,5T at 55km/h)
Reability: 4.5 million of operations without any failure neither part replacement
Standards: ISO EN 124 – E600 Class – Accepted vertical load: 60T per axle / In compliance with NFP98-310 standard / In compliance with the French PMR decree
Dimensions (mm): Ø200 x H750 I Ø250 x H750
