Features
- Single Pole Changeover Relay
- Positive or Negative Trigger
- Low Battery Dropout Function
- Volt-Free Connections
- Fused Power Output
- Easy Installation
- Panel or Chassis Mountable
| Nominal Coil Voltage | 12VDC |
| Max Switch Capacity | 1A @ 24VDC / 1A @ 120VAC |
| Power | 35mA active at 13.8VDC / 3mA quiescent at 13.8VDC |
| Temp. Range | -25°C to +70°C |
| Life | 1,000,000 Mechanical Operations |
| Operation Time | Max 5ms to Operate / Release |
| Dimensions | 55mm H x 55mm W x 25mm D |
